URNDT 1717M Portable Flat Panel Detector for 320KV DR System

Product Details:

Place of Origin:China
Brand Name:UNIREW
Model Number:1717M

Payment & Shipping Terms:

Minimum Order Quantity:1 set
Packaging Details:ABS
Delivery Time:3-7 days
Payment Terms:TT
Detailed Product Description
Features:
- Proven radiation hard a-Si sensor technology
- 43*43 cm2 imaging area
- 139 pm pixel pitch
- 16-bit ADC for high dynamic range
- Optical fiber interface without image loss
- Energy range from 40 kV ~ 320kV
- Fast speed, high throughput
- Easy software and system integration

Summary:
1717M is a 17-inch radiation hard a-Si FPD for real-time imaging. The detector supports frame rates up to 18 fps, and the 16 bit ADC provides high dynamic range and excellent contrast-to-noise ratio. The detector has an industrially rugged design, which provides high radiation resistance, wide environmental capabilities, and overall high reliability. Data communication is accomplished via an optical interface. The NDT 1717M is suitable for industrial NDT applications such as in casting inspections and SMD counting.

Software:
The software SDK provides support for detector calibration, configuration, image acquisition, pre-processing and viewing on an end-user tablet or workstation running the MS Windows operating system. With its exceptional image quality and reliability, the 1717M is an excellent choice for portable field inspection applications or IED/EOD based security scenarios.

Technical Specifications:
Detector Technology: Amorphous Silicon
Scintillator: Csl / DRZ-Plus
Pixel Pitch (pm):  139
Pixel Matrix: 3072 x 3072
Active Area (mm2): 427 x 427
Spatial Resolution (Ip/mm): 4
AD Conversion (bit): 16
Frame Rate (fps): 1
Maximum X-ray Exposure Window (s): 180
Data Interface: wired: GigE ( N100 Mbps) wireless: 802.11 a/g/n ( N 100mbps )
Trigger Mode: Software
X-ray Energy Range: 40kV ~ 320kV
Radiation Hardness (Gy): 2000
Ingress Protection: IP20
Dimensions (mm): 470 x 470 x 35
Car Charger: Yes
Weight (kg): 4.0
Power Dissipation (W): 25
Operating Temperature(°C): -10*35
Storage & Transport Temperature with Package (°C): -20 ~ 55
Operating Humidity (% RH): 20 ~ 90 (Non-Condensing)
Storage & Transport Humidity with Package (% RH): 10 ~ 90 (Non-Condensing)
