Features:

- Proven radiation hard a-Si design

- 25x30 cm2 imaging area

- 125 pm pixel pitch with 16-bit ADC for more image details

- Up to 180 sec. X-ray exposure window

- Rugged design, withstand 1m drop

- Robust wired and 5G wireless data interface

- Narrow dead space edge (< 7 mm)

- 2.5 hours battery capacity



Summary:

1012MA is a 10x12-inch wireless and portable amorphous silicon flat panel detector. The detector features a compact and industrially rugged design, which provides high radiation resistance, wide environmental capabilities, and overall high reliability. Data and signal communication is achieved either via a wired or a wireless interface.



Software:

The software SDK provides support for detector calibration, configuration, image acquisition, pre-processing and viewing on an end-user tablet or workstation running the MS Windows operating system. With its exceptional image quality and reliability, the 1012MA is an excellent choice for portable field inspection applications or IED/EOD based security scenarios.



Technical Specifications:

Detector Technology: Amorphous Silicon

Scintillator: Csl / DRZ-Plus / DRZ-STD

Pixel Pitch (pm): 125

Pixel Matrix: 2000x2400

Active Area (mm2): 250 * 300

Spatial Resolution (Ip/mm): 4

AD Conversion (bit): 16

Frame Rate (fps): 1

Maximum X-ray Exposure Window (s): 180

Data Interface: wired: GigE ( N100 Mbps) wireless: 802.11 a/g/n ( N 100mbps )

Trigger Mode: Software

X-ray Energy Range: 40kV ~ 320kV

Radiation Hardness (Gy): 2000

Ingress Protection: IP54

Dimensions (mm): 340 x 291 x 18

Car Charger: Yes

Weight (kg): 2.3

Power Dissipation (W): 17

Operating Temperature(°C): -10*40

Storage & Transport Temperature with Package (°C): -20 ~ 55

Operating Humidity (% RH): 20 ~ 90 (Non-Condensing)

Storage & Transport Humidity with Package (% RH): 10 ~ 90 (Non-Condensing)
